Product Description

The Relay is part of a wireless rocker-switch control system used to turn compatible heaters ON and OFF. It is hardwired to the heater and receives signals from wireless wall switches or remote controls.

The relay is suitable for 120V, 208V, and 240V applications and supports a maximum current of 20 amps. One relay is required for each heater. It also includes an Auto-Off function with selectable 30-minute, 60-minute, or 120-minute settings.

Key Features

  • Wireless Control: Receives signals from compatible wireless rocker switches and remote controls to operate the heater.
  • Voltage Compatibility: Suitable for 120V, 208V, and 240V applications.
  • 20-Amp Maximum: Rated for a maximum current of 20 amps.
  • One Relay Per Heater: One relay is required for each heater.
  • Auto-Off Function: Can automatically turn the heater OFF after 30, 60, or 120 minutes.
  • Zone Heating Support: Multiple relays can be controlled by a single rocker switch for zone heating.
  • Continuous Operation: The relay's factory setting is continuously ON.
  • Indoor Installation: The relay is to be mounted indoors only and protected from the environment.
  • FCC Approved: The control products are FCC approved for North America.

Specifications

  • Product Type: Heater Relay
  • Voltage Compatibility: 120V, 208V, and 240V
  • Maximum Current: 20 amps
  • Relay Requirement: 1 relay per heater
  • Auto-Off Timer: 30 minutes, 60 minutes, or 120 minutes
  • RF Communication: 902 MHz EnOcean® Protocol
  • FCC ID: SZV-STM300U
  • Certifications: UL 60730 (safety); UL 2043 (plenum)
  • Storage Temperature: -4°F to 176°F
  • Dimensions: 2.11" x 1.6" x 1.09"

Compatibility

  • Compatible With: 120V, 208V, and 240V heaters through the compatible relay control system.
  • Control Compatibility: Wireless rocker switches and remote controls can be linked to the relay.

Installation

  • Mounting Location: The relay is to be mounted indoors only and protected from the environment.
  • Mounting Method: Can be mounted inside a standard junction box or attached using a standard knockout and thread connector with nut.
  • Electrical Enclosure: A non-metal electrical enclosure is recommended for best RF transmission
